Bolt 6 LT TX is a wireless video transmitter that supports up to 1080p60 10-bit 422 HDR video over 3G-SDI, or 4K30 over HDMI. Bolt 6 uses Teradek’s patented Zero-Delay silicon chip to send wireless video over 5GHz and 6GHz radio frequencies.
Bolt 6 LT TX offers three line-of-sight options: 750 ft., 1500 ft., and the MAX model, which can be configured for up to 5,000 ft when using the optional Array Antenna and Broadcast Mode.
The Transmitter is cross-compatible with the entire Bolt 4K Series – including Bolt 4K, Bolt 4K LT, and the Bolt 4K Monitor Modules – giving you the option to expand your workflow requirements. Link up to 6 receivers to one transmitter, or unlimited receivers when used in Broadcast Mode (available on MAX models).
The 750 model includes V (vertical) Antennas. 1500 and MAX models include both V Antennas and H (horizontal) antennas. H Antennas are designed to maximize signal robustness in the most challenging RF environments.
Optionally, the 750 model of Bolt 6 LT TX can include permanent internal antennas to allow for reliable zero-delay transmission in a more compact and durable form factor.
KEY FEATURE
- Supports New 6 GHz Frequency Band
- Transmit Video up to 5000' Line of Sight
- Transmit up to 4K30 to up to 6 RXs
- Integrated Flexible H Antenna
- Supports up to 4K30 HDMI, 10-Bit 4:2:2
- Up to 1080p60 3G-SDI Input, Zero Delay
- 3G-SDI Loop Output, LUT Output Control
- Also Compatible with Bolt 4K Receivers
- Bluetooth Mobile App, Spectrum Analyzer
- Unlimited Receivers in Broadcast Mode
IN THE BOX
- Teradek Bolt 6 LT MAX 3G-SDI/HDMI Wireless Transmitter
- 2-Pin to D-Tap Power Cable (18")
- USB 2.0 Type-A Male to Micro-USB Male Cable (39")
- HDMI Type A Male to Male Cable (18")
- BNC SDI Cable (10")
- AC Adapter with Cable (6')
- Titling Antenna
- Mushroom Antenna
- Limited 1-Year Manufacturer Warranty
